M-Bus Master / USB - Converter HD67024

The HD67020 and HD670021 are M-Bus / RS232 - Converter (transparent converter). This series allow to read/write M-Bus Slaves devices by RS232, ensuring galvanic isolation between M-Bus and RS232. HD67020 are Plug&Play devices and they allow to connect up to 10 M-Bus Slaves to RS232. HD67021 are Configurable devices with Logic Inside and they allow to connect up to 250 M-Bus Slaves to RS232

Talk to Our Experts Download Datasheet

Baud Rate and Parity changeable with software. Mountable on 35mm Rail DIN; Power Supply 15…21V AC or 18…35V DC; Temperature range -40°C to 70°C.

Very easy to configure Microprocessor for queue data control Electrical isolation Industrial temperature range: -40°C / 70°C (-40°F / 158°F

  • HD67024-B2-20 support up to 20 M-Bus devices
  • HD67024-B2-40 support up to 40 M-Bus devices
  • HD67024-B2-80 support up to 80 M-Bus devices
  • HD67024-B2-160 support up to 160 M-Bus devices
  • HD67024-B2-250 support up to 250 M-Bus devices.

See Related Products

OPC UA Client / Modbus Slave - Converter HD67B09-2-B2 , HD67B09-5-B2

OPC UA Client / Modbus Slave - Converter HD67B09-2-B2 , HD67B09-5-B2

M-Bus Master / Modbus Slave – Converter ( Modbus Slave Port: USB ) HD67076

M-Bus Master / Modbus Slave – Converter ( Modbus Slave Port: USB ) HD67076

BACnet Slave / Modbus TCP Slave - Converter HD67674-IP
