8-CH NTC Module With Modbus RTU Protocol Z-8NTC

The Z-8NTC is an 8 channels NTC temperature converter with Modbus RTU protocol. For the communication can be used the USB or the RS485 port. The device can measure up to 8 NTC (each channel can be individually configured). The powerful Easy Setup software can be used for obtain the NTC parameters in a simple way.

Talk to Our Experts Download Datasheet

16-bit A/D conversion on three adjustable scales 100 Ω – 10 kΩ, 1 kΩ –100 kΩ, 5 kΩ – 500 kΩ.
0.5% accuracy on resistance value.
Measurement available in the following types: Resistance (Ω) or Temperature (°C, °F, K) on Integer 32-bit and Floating point 32-bit, direct or swapped.
Conversion From temperature to resistance with Steinhart-Hart high equation for high accuracy
Each channel can be individually enabled and configured.

Programmable filter for reading stabilization.
Conversion time: 500 ms for all channels
Linearization through configuration software for sensors: NTC, COSTER, KTY with Beta or Measure Points
Easy power supply and serial bus wiring by means of the Seneca Z-BUS housed in the DIN rail.
Removable screw terminals for section Max. 2.5 mm cable.

Power supply : 10 – 40 Vdc 19 – 28 Vac 50 – 60 Hz NTC
Inputs : Generic NTC with user-definable curve
Measurement range : 1k resistance, Range from 100Ω to 10kΩ.
Dimension : 17,5 x 102,5 x 111 mm
