DC current isolator Z110

Z110 is a 4..20mA isolator powered through the input loop. It does not require any auxiliary power supply. Z110 is available in two different version: Z110S (single channel) or Z110D (double channel). A 2-way galvanic isolation between input // output circuits assures the integrity of your datas.

Talk to Our Experts Download Datasheet

  • Isolation 3.500 Vac
  • Lightning impulse withstand voltage6,5 kV
  • Input/Output: 0..20, 4..20 mA
  • Sensor supply 2 wire technique (max 20 mA)
  • Dimension 100x 112 x 18 mm (l x h x w)
  • Fast mounting on DIN rail 46277

  • Z110 is available in two different version: Z110S (single channel) or Z110D (double channel).
  • A 2-way galvanic isolation between input // output circuits assures the integrity of your datas.

  • Power supply : From the 4-20 mA input loop
  • Max consumption : 1,6W (@24Vdc, 20mA output); 2,5W (max)
  • Power transducers : No
  • Accuracy : 0,1%
  • Isolation : 1.500 Vac (2 way)
