Galvanic Isolator Z109S-DI

Z109S-DI is a device that allows to isolate and convert a 0/4 - 20 mA signals. The device can power also all 2-wire sensors providing a stabilized voltage of 20 V and a max current of 20 mA with short-circuit protection. A 3-way galvanic isolation of 3.500 Vac among Power supply // input // output circuits assures the integrity of your data.

Talk to Our Experts Download Datasheet

  • Isolation 3.500 Vac (3 way)
  • Lightning impulse withstand voltage6,5 kV
  • Input/Output: 0..20, 4..20 mA
  • Sensor supply 2 wire technique (max 20 mA)
  • Dimension 100x 112 x 18 mm (l x h x w)
  • Fast mounting on DIN rail 46277
  • Enclosure PBT, black color

  • A 3-way galvanic isolation of 3.500 Vac among Power supply // input // output circuits assures the integrity of your data.
  • Z109S-DI is a device that allows to isolate and convert a 0/4 - 20 mA signals.
  • The device can power also all 2-wire sensors providing a stabilized voltage of 20 V and a max current of 20 mA with short-circuit protection.

  • Power supply : 10-40 Vdc; 19-28 Vac
  • Max consumption : 2,5 W
  • Power transducers : Active input 2 wire (20 Vdc)
  • Insulation : Safety insulation < 300 V~ referred to ground CAT II
  • Input protection : 30 V continuously.
