4-CH DC current-voltage A/D convert er Z-4TC-D

Z-4TC-D allows to acquire up to N.4 Thermocouple sensors (J, K, E, N, S, R ,B ,T) through a PLC with only digital input/output. The PLC interface is based on three PNP-type signals suited for connection to most PLCs available in the market. The interface is composed of a CLOCK signal generated by the PLC (transistor output), a DATA signal and STROBE signal generated by the module.

Talk to Our Experts Download Datasheet

  • Z-4TC-D allows to acquire up to N.4 Thermocouple sensors (J, K, E, N, S, R ,B ,T) through a PLC with only digital input/output.
  • The PLC interface is based on three PNP-type signals suited for connection to most PLCs available in the market.

  • The interface is composed of a CLOCK signal generated by the PLC (transistor output), a DATA signal and STROBE signal generated by the module.

  • Power supply : 19..40 Vdc / 19..28 Vac / 50-60 Hz
  • Max consumption : 2,5 W
  • Isolation : 1.500 Vac (3 way)
  • Protection : IP20
  • Mounting : 35 mm DIN rail guide
