Standard Platinum Thermoresistance Pt100

SENECA offers also sensors calibration service for Pt100 and / or thermoresistances including sensor installed aboard.Standard Pt100 probe (IEC 751), 3 wires technique, A or B class.

Talk to Our Experts

  • Standard cast aluminum weatherproof thermal head.
  • Ceramic connection socket.
  • Sensor wetted parts: AISI 316.
  • Sheath diameter: from 6 up to 8 mm (other measures available on demand).
  • Process connection from ½” g.m. (other measures available on demand).

  • Atmosphere Probe model (ABS, IP65) available on demand.
  • DIN B head type allows the host a signal transmitter giving out a 4..20 mA value, For example, Seneca FlexTop 2201 is a microprocessor converter for Pt100 into 4..20 mA. FlexTop2201 is programmable via PC with softwar toolkit.

As per datasheet.
