- On-line measurement
- 2 wire system
- 4-20 mA DC output
- Head Mount Transmitter
- Cold junction Compensation for thermocouple input
Brix series TT-01 are head mount type temperature transmitters used for various industrial applications. It can accept input from RTD, J & K type of thermocouples & temperature signal is transmitted in the form of electrical 4 – 20 mA signal. Span / Zero adjustments are easily accessible. These transmitters are suitable for any make of sensor.
- Power Supply : 24 V DC
- Output : 4 – 20 mA DC (2 Wire Non-Isolated)
- Accuracy : +/- 0.25% of F. S.
- Power Consumption : < 40 mW
- Mounting : DIN Rail / Head Mount
- Ambient Conditions : Temperature -20 to 55 °C / Humidity 5 to 95% non condensing
- Certification : CE
|
Datasheet |
|
No 3D model available for this product.
